国外公司采购牙科涡轮清洁器配件 -- 20250617

国外公司采购牙科涡轮清洁器配件

具体要求请联系张小姐：

Eamil : Lynne，

Tel，WeChat : 13530128923

Details:

- We do not have any design or manufacturing files for this project. 公司没有任何的设计图或者生产图纸

- Timeline: The project is not very urgent, but I would like to put it to work ASAP. 没有很着急，但是也得着手开始了

- Expected quantities are 50 sets to 100 sets per order. 每个订单是50套或者100套

1. The device is a dental turbine cleaner. 该设备是一种牙科涡轮清洁器

This is a typical dental turbine :下图是一个典型的牙科涡轮机

2. The user is connecting the cleaner (The Grip assy ) to the turbine. 需要把给我们询价的产品（The Grip assy) 跟涡轮机链接起来

3. The device is made of some parts that you need to produce by CNC machining and some parts that you need to source - off the shelf. 这些询价的产品有些是需要买现货的有些是需要CNC加工的

4. Off-the-shelf  parts number  1 , 2 , 3   买现货的看附件图1，2，3

Lookin  the web under: "Spare parts for dental turbine." There are a lot of suppliers, you will need to find the ones that are most similar to the sample we provided and better that it will be the very same ones.

公司让我们在网上按照关键词“ Spare parts for dental turbine" 来搜可以看到很多供应商，需要找到能生产跟我们实样最近的供应商。

5. Parts to CNC produce from POM - Delrin 500 or equivalent: Grip, Screw, Plunger  需要用POM或者 Delrin 500或者替代材料来做的部件是 Grip, Screw, Plunger

6. Assembly notes: 装配注意事项：

- Part #3 above is glued to the Grip. You mage cut the grip sample to disassemble part 3 and see how it's glued.  Part#3 是粘在Grip上的，可以割开 Grip样品来看怎么跟 part 3# 组装

We will need to discuss how to do the glue process, but that we can do later. 后续再讨论怎么粘连

- Need to place an O-RING on the Plunger.  Plunger 部件上面需要一个O-RING

- The Plunger O-Ring must fit and slide smoothly inside the hole of the screw. 这个O-RING 需要跟螺丝很丝滑的适配

- In the Grip and Plunger there is a thread, It's not critical to copy the very same thread, as long as the thread fits. 部件Grip 和 Plunger之间有螺纹，不需要完全copy到一模一样，只要两者的螺纹适配就可以。

7. Clamp device - This device needs to be copied as is. Material: SS316L.  这个部件Clamp device需要完全copy,材质是 SS 316L

Note that there is a spring inside the handle. Unscrew to see it. Spring material is SS. 注意下，把手里面有个弹簧，打开螺丝可以看到，弹簧的材质是不锈钢。

Regards
